Introduction 5
1.3.1 Dimensions of the RSTi-EP Components
Height (H)
Width (W)
Depth (D)
Network adapter
120.0 mm (4.72 in)
52.0 mm (2.05 in)
76.0 mm (2.99 in)
I/O module
120.0 mm (4.72 in)
11.5 mm (0.45 in)
76.0 mm (2.99 in)
End plate
120.0 mm (4.72 in)
3.5 mm (0.14 in)
76.0 mm (2.99 in)
End bracket
120.0 mm (4.72 in)
8.0 mm (0.32 in)
mm (1.42 in)
1.3.2 Double-click Installation
The RSTi-EP station modules can be installed quickly and simply. When attaching the
module to the DIN rail, a clear clicking noise can be heard, which means that the module has
clicked into place. In the second step, which involves pushing the module being installed
together with the neighboring module, a further clicking noise indicates that the modules
have been correctly connected to each other.
