User Manual Section 4
GFK-2958L May 2021
Detailed Descriptions of the Fieldbus Network Adapters 136
Class
Attribute
Get
Set
NV
1)
Data Type
2)
Name
Description
hex
dez
0x6E
110
x
UINT
Output Bit Length
Length of output data in Bit
0x6F
111
x
UINT
Parameter Byte
Length
Length of parameter data in
Byte
0x70
112
x
UINT
Diag Byte Length
Length of diagnosis data in Byte
0x71
113
x
Array of BYTE
Process Data In
Input data of the module
0x72
114
x
x
Array of BYTE
Process Data Out
Output data of the module
0x73
115
x
x
Array of BYTE
Parameter Data
Parameter data of the module
0x74
116
x
Array of BYTE
Diagnosis Data
Diagnosis data of the module
0x75
117
x
Array of BYTE
Process Alarm Data
Process alarm data of the
module
Process Data 0x66 (102)
Instance 0x00 (0)
0x64
100
x
UINT
Revision
Revision of this object
0x65
101
x
UINT
Max Instance
Highest possible instance of this
object
0x66
102
x
UINT
Number of Instances
Current number of instances
0x67
103
x
UINT
Max Class Attribute
ID of the last attribute of this
class in instance 0
Instance 0x01 (1)
0x64
100
x
x
USINT
Max Attributes
ID of the last instance attribute
0x65
101
x
Array of BYTE
Process Data In
All input data
0x66
102
x
UINT
Length Process Data In
Total length of input data
0x67
103
x
x
Array of BYTE
Process Data Out
All output data
0x68
104
x
UINT
Length Process Data
Out
Total length of output data
0x69
105
x
Array of 8 BYTE
Diag Status
Diagnosis messages as in
assembly
0x6A
106
x
Array of 8 BYTE
Diag Control
Diagnosis control as in
assembly
Module Parameter 0x67 (103)
Instance 0x00 (0)
0x64
100
x
UINT
Revision
Revision of this object
0x65
101
x
UINT
Max Instance
Highest possible instance of this
object
0x66
102
x
UINT
Number of Instances
Current number of instances
0x67
103
x
UINT
Max Class Attribute
ID of the last attribute of this
class in instance 0
Instance 0x01 ... 0x40 (1 ... 64)
0x64
100
x
x
UINT
Max Attributes
ID of the last instance attribute
0x65
101
x
x
UINT
Parameter
Parameters of the module
1) Nonvolatile (data are saved permanently)
2) For the description of data types refer to table Data types
