Emerson PACSystems RSTi-EP - Page 198

User Manual Section 5
GFK-2958L May 2021
Detailed Description of I/O Modules 184
1.2
--
1.3
Yellow: Output 1 active
1.4
--
2.1
Yellow: Output 2 active
2.2
--
2.3
Yellow: Output 3 active
2.4
--
3.1
Yellow: Output 4 active
3.2
--
3.3
Yellow: Output 5 active
3.4
--
4.1
Yellow: Output 6 active
4.2
--
4.3
Yellow: Output 7 active
4.4
--
For error messages refer to Section 12, LED Indicators and Troubleshooting.
Figure 92: Block Diagram EP-2218
