Emerson PACSystems RSTi-EP - 5.29 Analog Input Module EP-3468

User Manual Section 5
GFK-2958L May 2021
Detailed Description of I/O Modules 316
Name
Bytes
Bit
Description
Default
Diagnostic bits per
channel
5
Number of diagnostic bits per channel
8
Number of channels
6
Number of similar channels per module
4
Channel error
7
0
Error at channel 0
1
Error at channel 1
2
Error at channel 2
3
Error at channel 3
4-7
Reserved
0
Channel error
8
8-15
Reserved
0
Channel error
9
16-23
Reserved
0
Channel error
10
24-31
Reserved
0
Channel 0 error
11
0
Parameter error
1
Overload
2
Line break sensor supply
3
Fuse blown
4
Line break signal
5
Reserved
0
6
Lower limit exceeded
7
Upper limit exceeded
Channel 1 error
12
0
Parameter Error
1
Overload
2
Line break sensor supply
3
Fuse blown
4
Line break signal
5
Reserved
0
6
Lower limit exceeded
7
Upper limit exceeded
Channel 2 error
13
0
Parameter Error
1
Overload
2
Line break sensor supply
3
Fuse blown
4
Line break signal
5
Reserved
0
6
Lower limit exceeded
7
Upper limit exceeded
Channel 3 error
14
0
Parameter Error
1
Overload
2
Line break sensor supply
3
Fuse blown
4
Line break signal
5
Reserved
0
6
Lower limit exceeded
7
Upper limit exceeded
Channel 4 error
to
Channel 31 error
15 - 42
0 - 7
Reserved
0
Time stamp
43-46
Time stamp [
μ
s] (32-bit)
