User Manual Section 5
GFK-2958L May 2021
Detailed Description of I/O Modules 368
Up to three neutral conductors (N) can be connected with the first connector. One phase
conductor (at LX) and one 1 A conductor (at LX‘ 1A) or one 5 A conductor (at LX‘ 5A) can
be connected to each of the other three connectors. The three current measurement
connections can be used concurrently all for the same measurement range (1 A or 5 A)
only. The mains connection must be fused with 1 A/5 A respectively.
A status LED is assigned to each channel.
CAUTION
Possible danger to life:
Always Disconnect the Power Supply to the station before working with the module and
secure the station against being switched on again.
The touch-safe protection of this module is only provided with the DIN rail earthed
properly.
Make sure that the DIN rail is connected to PE by earth terminals before commissioning
the module.
Attention
The module can be destroyed by overload!
The measurement connections L1', L2' and L3' are internally
connected to L1, L2, and L3 via a shunt. Neutral conductors
must not be connected to L1', L2' and L3'!
The module is temporary overload-capable (max. 5 seconds up
to the fivefold current). Make sure that there will be no higher
current peaks (e.g. by saturating the transformer)!
Figure 202: Connection diagram EP-1813: Delta Connection (Example Measurement 1
A)
