Emerson PACSystems RSTi-EP - Page 65

User Manual Section 3
GFK-2958L May 2021
Configuration 51
Part No.
Module
Configuration
Parameter
Diagnostics
Process data
Bytes
Bytes
Bytes
Input
Bytes
Output
Bytes
EP-5212
2 Channel Frequency Measurement, 100
kHz
3
5
47
20
12
EP-5261
1 Channel Serial Communications, 232,
422, 485
3
9
47
16
16
EP-5311
1 Channel SSI Encoder, BCD or
Gray-Code Format, 5/24 Vdc
3
11
47
6
0
EP-5422
2 Channels PWM Output, Positive Logic,
24Vdc, 0.5 A
3
11
47
4
12
EP-5442
2 Channels PWM Output, Positive Logic,
24Vdc, 2 A
3
11
47
4
12
EP-5324
IO-Link Communication module, 4
Channels
3
29
47
1)
1)
EP-3164
Analog Input, 4 Channels Voltage/Current
16 Bits
2-, 3-, or 4-Wire
3
9
47
8
--
EP-3264
Analog Input, 4 Channels Voltage/ Current
16 Bits with Diagnostics
2-, 3-, or 4-Wire
3
11
47
8
--
EP-3664
Analog Input, 4 Channels Voltage/ Current
16 Bits with Diagnostics
2-, 3-, or 4-Wire, Differential
3
11
47
8
--
EP-3124
Analog Input, 4 Channels Voltage/ Current
12 Bits 2-, 3-, or 4-Wire
3
9
47
8
--
EP-3804
Analog Input, 4 Channels TC 16 Bits with
Diagnostics 2-, 3-, or 4-Wire
3
31
47
8
--
EP-3368
Analog Input, 8 Channels Current
16 Bits 2-, 3-, or 4-Wire
3
13
47
16
--
EP-3468
Analog Input, 8 Channels Current
16 Bits 2-, 3-, or 4-Wire, Channel Diagnostic
3
13
47
16
--
EP-4164
Analog Output, 4 Channels
Voltage/Current 16 Bits
2-, 3-, or 4-Wire
3
15
47
--
8
EP-4264
Analog Output, 4 Channels Voltage/
Current 16 Bits with Diagnostics
2-, 3-, or 4-Wire
3
16
47
--
8
EP-3704
Analog Input, 4 Channels RTD 16 Bits with
Diagnostics 2-, 3-, or 4-Wire
3
31
47
8
--
EP-1813
Power Measurement Module, 8 Channels
3
30
47
16
16
EP-1901
1 Safe Feed-Input, 24 Vdc
3
--
47
4
--
EP-1922
1 Safe Feed-Input, 24 Vdc
3
--
47
4
--
EP-1902
2 Safe Feed-Inputs, 24 Vdc
3
--
47
4
--
Max. data (in
bytes)
244
244
244
244
244
