User Manual Section 3
GFK-2958L May 2021
Configuration 53
2 Channel Frequency Measurement, 100
kHz
1 Channel Serial Communications, 232,
422, 485
1 Channel SSI Encoder, BCD or Gray-Code
Format, 5/24 Vdc
2 Channels PWM Output, Positive Logic,
24Vdc, 0.5 A
2 Channels PWM Output, Positive Logic,
24Vdc, 2 A
IO-Link Communication module, 4
Channels
Analog Input, 4 Channels
Voltage/Current 16 Bits 2-, 3-, or 4-Wire
Analog Input, 4 Channels
Voltage/Current 16 Bits with Diagnostics
2-, 3-, or 4-Wire
Analog Input, 4 Channels Voltage/
Current 16 Bits with Diagnostics
2-, 3-, or 4-Wire, Differential
Analog Input, 4 Channels
Voltage/Current 12 Bits 2-, 3-, or 4-Wire
Analog Input, 4 Channels TC 16 Bits with
Diagnostics 2-, 3-, or 4-Wire
Analog Input, 8 Channels Current
16 Bits 2-, 3-, or 4-Wire
Analog Input, 8 Channels Current
16 Bits 2-, 3-, or 4-Wire, Channel
Diagnostic
Analog Output, 4 Channels Voltage/
Current 16 Bits 2-, 3-, or 4-Wire
Analog Output, 4 Channels Voltage/
Current 16 Bits with Diagnostics
2-, 3-, or 4-Wire
Analog Input, 4 Channels RTD 16 Bits
with Diagnostics 2-, 3-, or 4-Wire
Power Measurement Module, 8 Channels
1 Safe Feed-Input, 24 Vdc
2 Safe Feed-Inputs, 24 Vdc,
Programmable Delay
2 Safe Feed-Inputs, 24 Vdc
1)
The available data lengths are 4 bytes, 8 bytes, 16 bytes, 32 bytes, 64 bytes & 128 bytes along with the 2 bytes process
data for IO-Link module.
