User Manual Section 3
GFK-2958L May 2021
Configuration 57
Analog Input, 4 Channels
Voltage/Current 16 Bits with
Diagnostics 2-, 3-, or 4-Wire
Analog Input, 4 Channels Voltage/
Current 16 Bits with Diagnostics
2-, 3-, or 4-Wire, Differential
Analog Input, 4 Channels
Voltage/Current 12 Bits 2-, 3-, or 4-Wire
Analog Input, 4 Channels TC 16 Bits with
Diagnostics 2-, 3-, or 4-Wire
Analog Input, 8 Channels Current 16
Bits 2-, 3-, or 4-Wire
Analog Input, 8 Channels Current 16
Bits 2-, 3-, or 4-Wire, Channel
Diagnostic
Analog Output, 4 Channels Voltage/
Current 16 Bits 2-, 3-, or 4-Wire
Analog Output, 4 Channels Voltage/
Current 16 Bits with Diagnostics
2-, 3-, or 4-Wire
Analog Input, 4 Channels RTD 16 Bits
with Diagnostics 2-, 3-, or 4-Wire
Power Measurement Module, 8
Channels
1 Safe Feed-Input, 24 Vdc
2 Safe Feed-Inputs, 24 Vdc,
Programmable Delay
2 Safe Feed-Inputs, 24 Vdc
1)
Depending upon on the assembly used.
2)
You can select the length of the process input data and process output data from 2 bytes to 128 bytes including the 2
Byte process data for IO-Link module using Class 67 (module parameter), instance (slot of the EP-5324) Attribute 65
(length of input data) or Attribute 66 (length of output data).
