ETC Element 2 User Manual

Attribute Section
178
Database Section
180
Augment3d Section
182
Using Device List
182
Clearing the Patch
187
Update Profile
187
Fixture Editor
187
Setup
203
About Setup
204
System Settings
204
User Settings
213
Device Settings
215
Console Status Display
221
Manual Control
223
About Manual Control
224
Using Channel Faders On Element 2
224
Selecting Channels
224
Setting Intensity
230
Manual Control of Non-intensity Parameters (NPs)
231
Home
243
Multiple Intensity Channels
244
Multicell Fixtures
244
Lamp Controls
246
Using [+%] and [-%]
246
Remainder Dim
247
Highlight and Lowlight
249
Sneak
250
Staging Mode
251
Select Keys
252
Channel Check
254
Address at Level
254
Address Check
255
Table of Contents iii

ETC Element 2 Specifications

General

DMX Outputs	2
Touchscreen	Yes
Networking	Ethernet
Type	Lighting Control Console
Master Faders	2
Encoders	4
Ethernet Ports	2
USB Ports	4
Video Output	DisplayPort
Power Input	100-240VAC, 50/60Hz
Power Supply	Internal
Control Channels	6144
Output	Art-Net
Display	Multi-Touch LCD
Storage	Solid State Drive (SSD)
