502 Eos Apex, Eos Ti, Gio, Gio @5, Ion Xe, Ion Xe 20, and Element 2 User Manual
Position [@] [Enter] will remove the pose (position and orientation) of the selection.
Orientation [@] [Enter] will reset the orientation of the selection to (0,0,0).
Editing Fixture Position and Rotation
Fixture position and rotation can also be edited in
Augment3d Edit Mode (on page479)
using
tools available in the toolbar or in the Inspector.
Any changes made to fixture position in Augment3d will automatically update the values in
Patch. Similarly, any change made viaPatch will automatically update the fixtures in
Augment3d.
Setting Orientation for Conventional Fixtures in Patch
The Orientation property for conventional (non-automated) fixtures is used to aim static
lighting fixture at the correct point.
1. Navigate to Patch.
2. Select conventional fixtures via the command line, or by selecting them in Augment3d.
The fixtures will light up to indicate their selection.
Note:
You do not need to enter Augment3d Edit Mode to select fixtures.
3. Aim the fixtures at their intended target using a long selection, or SHIFT+left mouse.
