Nodes 5-12
Diagnostic Menu: RKD
In addition to displaying system
menus for programming and so
on, the keypad has its own
diagnostic menu. Access to this
diagnostic menu is available when
a keypad node is isolated from the
ringnet (communications lines
removed).
Alternatively, the same node
information can be accessed
through the Node Configure
menu, Monitor submenu. See
Node Configure->Nodes-
>Information->Monitor in 3GS
Programming for further
information.
This menu provides you with data
on the keypad’s current
configuration and allows locally
related operations to be
performed – such as, adjusting the
display parameters and switching
the on-board output.
