DMP 128 FlexPlus • Remote Control and Configuration 131
Command ASCII command
(host to device)
Response
(device to host)
Additional description
IP Setup Commands
Set unit name
EX# CN} Ipn•X#]
Set unit name to factory
default
E•CN} Ipn•X2!]
View unit name
ECN} X#]
Set date/time
EX$ CT} Ipt•X$]
View date/time
ECT} X$]
View date/time in hex
E*CT} X2%]
View GMT offset
ECZ} X@]
Set DHCP on
E1DH} Idh1]
Set DHCP off
E0DH} Idh0]
View DHCP mode
EDH} X12)]
NOTE: The following commands affect the LAN port on a C AT model and the LAN 1 port on the C V AT.
Set IP address
EX%CI} Ipi•X%]
View IP address
ECI} X%]
View hardware address
(MAC)
ECH} X^]
In verbose modes 2 and 3:
IphX^]
Set subnet mask
EX&CS} Ips•X&]
View subnet mask
ECS} X&]
Set gateway IP address
EX%CG} Ipg•X%]
View gateway IP
address
ECG} X%]
KEY:
X@
= GMT Offset Value This represents hours and minutes (hh:mm) offset from Greenwich
Mean Time.
X#
= Unit Name A text string up to 63 characters drawn from the alphabet (A-Z),
digits (0-9), and minus sign/hyphen (-).
X$
= Local Date and Time
Format
MM/DD/YY-HH:MM:SS
X%
= IP Address xxx.xxx.xxx.xxx . Leading zeros in each of the 4 fields are optional
in setting values and are suppressed in responses.
X^
= Hardware MAC Address 00-05-A6-xx-xx-xx
X&
= Subnet Mask xxx.xxx.xxx.xxx . Leading zeros in each of the 4 fields are optional
in setting values and are suppressed in responses.
X2!
= Default Name Combination of unit model name and last 3 pairs of MAC address.
X2%
= Date and Time in Hex Date and time returned in 7 hex bytes (month, day, year, hour, min-
utes, seconds, and day of the week with Sunday = 1).
X4&
= Prefix (subnet mask bits) Subnet 255.255.0.0 is represented as a Prefix value of /16.
X12)
= DHCP Status 0 = off (default), 1 = on
