DMP 128 FlexPlus • Configuration Tools 81
To run a Macro:
1. Connect to the DMP 128 FlexPlus in Live mode (see Live and Emulate Panel on
page17).
2. Click Tools > Configure Macros.
3. From the Select Macro drop-down, choose the macro to be run.
4. Once the macro information is displayed, click Run Macro.
-or-
1. Connect to the DMP 128 FlexPlus in Live mode (see Live and Emulate Panel on
page17).
2. Select the macro to be run from the Run Macro drop-down in the tool bar.
Figure 137. Run Macro Drop-Down
To edit remote destinations:
1. Click Edit Remote Destinations from the Configure Macros dialog box.
2. Select an existing device from the Unique Device Name drop-down.
3. Edit the information for the device or click Delete to remove the selected device.
4. Click Apply to save changes made to the remote destination.
5. Click Close to close the Edit Remote Destinations dialog box.
NOTE: See step 3 on page 79 for information regarding adding a destination.
Manipulating Macro Actions
After a macro action has been fully configured, it can be cut, copied, pasted, inserted, or
deleted. Right-click the left-most box in the action line item (see figure 136,
3
on page78)
and select an option from the drop-down menu.
Figure 138. Macro Action Manipulation Drop-Down
To cut a macro action:
1. Right click the box furthest to the left in the action list item to be cut.
2. Select Cut. The action is removed from the list and placed in the clipboard.
To copy a macro action:
1. Right click the box furthest to the left in the action list item to be copied.
2. Select Copy. The action is copied to the clipboard.
figure 129. Run Macro Dropdown
figure 130. Macro Action Manipulation
