7.4 3.5-inch HDD configurations
7.4.1 Configuration with up to two 3.5-inch HDDs
Figure 60: Configuration with up to two 3.5-inch HDDs
The HDD numbering as listed in the ServerView RAID Manager:
Position Logical drive
number
ServerView RAID Manager display
name
[0] 0 Vendor Product (0)
[1] 1 Vendor Product (1)
7.4.2 Installing 3.5-inch non hot-plug HDDs
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: tool-less
Preliminary steps
▶
"Shutting down the server" on page 45
.
▶
"Disconnecting the power cord" on page 46.
Hard disk drive (HDD) / solid state drive (SSD)
TX1320 M5 Upgrade and Maintenance Manual 137
