Concluding steps
â–¶
"Reassembling" on page 54
.
â–¶
"Connecting the power cord" on page 57.
â–¶
"Switching on the server" on page 60.
17.4.5 Replacing the TPM
Field Replaceable Unit
(FRU)
Hardware: 40 minutes
Tools: Removing the system board:
– Phillips PH2 / (+) No. 2 screw driver
Replacing the TPM:
–
Bit screw driver
–
TPM bit insert
(*)
– flat nose pliers
–
thin slotted screw driver (2 x 0.4 mm)
(*)
(*)
For Japan:
– Dedicated TPM screw driver (CWZ8291A)
– TPM module fixing tool (S26361-F3552-L909)
CAUTION
â–¶
Advise your contact persons that they must provide you with all
recovery keys which belong to the system to restore them in the
TPM later.
Preliminary steps
â–¶
"Locating the defective server" on page 43.
â–¶
"Suspending BitLocker functionality" on page
71.
System board and components
TX1320 M5 Upgrade and Maintenance Manual 311
