Fujitsu PRIMERGY TX1320 M5 User Manual

4.10 Switching on the server
CAUTION
▶
Before switching on the server, make sure the side cover is closed.
In order to comply with applicable EMC regulations (regulations on
electromagnetic compatibility) and satisfy cooling requirements, the
server must not run while the side cover is removed.
▶
For more information, see "Important information" on page 29
.
▶
Press the On/Off button to start up the server
.
▶
Ensure that the power-on indicator is lit green.
4.11 Handling the 2.5-inch HDD cage
4.11.1 Removing the 2.5-inch HDD cage
Figure 16: Removing the HDD cage (A)
▶
Remove the four screws (see circles).
▶
Remove the cover from the HDD cage.
Basic hardware procedures
60 Upgrade and Maintenance Manual TX1320 M5
