Concluding steps
▶
"Reassembling" on page 54
.
▶
"Connecting the power cord" on page 57.
▶
"Switching on the server" on page 60.
▶
Update the system information of your server using the Chassis ID Prom
Tool, see "Using the Chassis ID Prom Tool" on page 96.
16.4 Removing the dust covers
Upgrade and Repair Unit
(URU)
Hardware: 15 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver
Preliminary steps
▶
"Shutting down the server" on page
45
.
▶
"Disconnecting the power cord" on page 46.
▶
"Getting access to the component" on page 48.
Removing the dust cover 5
Figure 192: Loosening the screw
Dust cover
TX1320 M5 Upgrade and Maintenance Manual 293
