5.25-inch slimline ODD
3.5-inch
RDX drive
Figure 149: Accessible drives mounting order
Accessible drive Max. #
5.25-inch bay 2 ODD 1
3.5-inch bay Backup drive 1
Table 4: Accessible drive mounting sequence
12.3 Optical disk drive (ODD)
12.3.1
Installing the ODD
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Tools: Phillips PH1 / (+) No. 1 screw driver
Preliminary steps
▶
"Suspending BitLocker functionality" on page 71
.
▶
"Shutting down the server" on page 45.
▶
"Disconnecting the power cord" on page 46.
▶
"Getting access to the component" on page 48.
Accessible drives
246 Upgrade and Maintenance Manual TX1320 M5
