14 Front USB connector
14.1 Installing a front USB connector
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver
Preliminary steps
▶
"Shutting down the server" on page 45
.
▶
"Disconnecting the power cord" on page 46.
▶
"Getting access to the component" on page 48.
Removing the FBU tray
▶
Remove the FBU tray, see Figure 126.
TX1320 M5 Upgrade and Maintenance Manual 273
