Fujitsu PRIMERGY TX1320 M5

Removing the FBU from the tray
A
Figure 126: Removing the FBU tray
▶
Press on the green tab (see close-up, A) to open the FBU tray.
▶
Pull out the FBU tray
.
Expansion cards and backup units
TX1320 M5 Upgrade and Maintenance Manual 217
