Install the Dual microSD 64GB Enterprise, see "Installing the Dual microSD
64GB Enterprise" on page 329
.
Concluding steps
â–¶
"Reassembling" on page 54.
â–¶
"Connecting the power cord" on page 57.
â–¶
"Switching on the server" on page 60.
17.8 System board
17.8.1 Replacing the system board
Field Replaceable Unit
(FRU)
Hardware: 50 minutes
Software: 10 minutes
Tools: Replacing the system board:
–
Phillips PH2 / (+) No. 2 screw driver
–
Magnifying glass for inspecting CPU socket springs
(recommended)
Replacing the TPM:
– Bit screw driver
– Flat nose pliers
–
TPM bit insert
(*)
–
Thin slotted screw driver (2 x 0.4 mm)
(*)
(*)
For Japan:
– Dedicated TPM screw driver (CWZ8291A)
– TPM module fixing tool (S26361-F3552-L909)
System board and components
TX1320 M5 Upgrade and Maintenance Manual 337
To Next Page
