16.2 Basic information
Figure 183: Dust cover kit
1 Dust cover 1
2
Dust cover 2
3
Dust cover 3
4 Dust cover 4
5 Dust cover 5
16.3 Installing the dust covers
Upgrade and Repair Unit
(URU)
Hardware: 15 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver
Preliminary steps
▶
"Shutting down the server" on page 45.
▶
"Disconnecting the power cord" on page 46.
▶
"Getting access to the component" on page 48.
Dust cover
288 Upgrade and Maintenance Manual TX1320 M5
