Concluding steps
▶
Dispose of the CMOS battery in accordance with local regulations
concerning special waste.
▶
"Reassembling" on page 54.
▶
"Connecting the power cord" on page
57.
▶
"Switching on the server" on page 60.
▶
BIOS settings are automatically reloaded. Time and date must be set
manually, see "Verifying the system time settings" on page 87.
You must manually change the BIOS settings according to the note
on your current BIOS settings, see "Note on BIOS settings recovery"
on page 301
.
17.4 Trusted Platform Module (TPM)
17.4.1 Position of the TPM
Slot 2
Slot 1
Slot 4
Slot 3
iRMC
S6
TPM
SATA ODD
Indicate CSS
0-3
FAN4 SYS
M.2
SSD1
HDD
LED
Clear
RTC
M.2
SSD2
Figure 199: Position of the TPM on the system board
1 TPM
System board and components
302 Upgrade and Maintenance Manual TX1320 M5
