Figure 118: Position of the FBU
1 FBU
9.6.2 Installing an FBU
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: tool-less
Preliminary steps
▶
"Shutting down the server" on page 45
.
▶
"Disconnecting the power cord" on page 46.
▶
"Getting access to the component" on page 48.
▶
"Disconnecting the front USB connector" on page 277.
Expansion cards and backup units
208 Upgrade and Maintenance Manual TX1320 M5
