Slot configuration PCIe root setting
Slot 4: x16
Slot 3: empty
1x 16 PCI Express
Slot 4: x16
Slot 3: x8, x4, x1
2x 8 PCI Express
Slot 4: x8, x4, x1
Slot 3: x8, x4, x1
2x 8 PCI Express
Slot 4: empty
Slot 3: x8, x4, x1
2x 8 PCI Express
Slot 4: x8, x4, x1
Slot 3: empty
2x 8 PCI Express
For system relevant information, see the hardware configurator of your
server available online at the following address:https://ts.fujitsu.com/
products/standard_servers/index.html
For Japan:
https://www.fujitsu.com/jp/products/computing/servers/primergy/
9.3 Handling slot brackets
9.3.1 Installing slot brackets
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver
Use the low profile bracket perforated for relevant controllers. No
bracket needed for installing the internal RAID controller in the internal
RAID riser module.
Expansion cards and backup units
TX1320 M5 Upgrade and Maintenance Manual 183
