Numbering of the HDD fan modules (2.5-inch HDD variant)
Figure 89: Numbering of the fan modules (2.5-inch HDD variant)
1 Fan 1 2 Fan 2
8.3 Replacing the HDD fan (3.5-inch HDD
variant)
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Tools: tool-less
Preliminary steps
▶
"Locating the defective server" on page 43
.
▶
"Shutting down the server" on page 45.
▶
"Disconnecting the power cord" on page 46.
▶
"Getting access to the component" on page 48.
Fans
TX1320 M5 Upgrade and Maintenance Manual 173
