Figure 68: Fastening the screws
▶
Fasten the two knurled screws (see circles).
Concluding steps
▶
"Reassembling" on page
54
.
▶
"Connecting the power cord" on page 57.
▶
"Switching on the server" on page 60.
To configure the installed HDD, see your controller manual.
7.4.3 Removing 3.5-inch non hot-plug HDDs
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: tool-less
Hard disk drive (HDD) / solid state drive (SSD)
TX1320 M5 Upgrade and Maintenance Manual 143
