18.2.3.2 ID, CSS and Global Error indicators
Figure 244: ID, CSS and Global Error indicators
1 ID indicator
2 Global Error indicator
3
CSS indicator
If CSS and Global Error indicators are located in the same place on the
I/O panel of the server, also check the indicators on the front panel to
determine if a CSS or Global Error event has been detected.
For more information on detected errors, see the System Event Log or
iRMC web interface.
ID indicator (1)
See also "iRMC-related status signals" on page 369.
Appendix A
TX1320 M5 Upgrade and Maintenance Manual 367
