Status Description
blue on The server has been highlighted using iRMC web
interface or the ID button on the front panel for easy
identification.
flashing blue The server has been highlighted for easy
identification using the iRMC (AVR) with disabled
local VGA output.
Global Error indicator (1)
See also "iRMC-related status signals" on page 369.
Status Description
of
f No critical event detected (non-CSS component).
orange on Prefailure event detected (non-CSS component).
flashing orange Non-CSS component failure detected.
Possible causes:
– System is out of the specified temperature range
–
Defective sensor
– CPU error
– Error detected by server management software
CSS indicator (1)
Status Description
off No critical event detected (CSS component).
orange on Prefailure event detected (CSS component).
flashing orange CSS component failure detected.
Appendix A
368 Upgrade and Maintenance Manual TX1320 M5
