Connect the cables to the RDX drive:
1 Power cable connector “RDX” to the connector on the RDX drive
2 USB cable to the RDX drive and to the connector “USB8” on the
system board
Concluding steps
▶
"Reassembling" on page 54.
▶
"Connecting the power cord" on page 57.
▶
"Switching on the server" on page 60.
▶
"Resuming BitLocker functionality" on page 91.
For the cable plan, see "Appendix B" on page 375
.
12.4.2 Removing the RDX drive
Field Replaceable Unit
(FRU)
Hardware: 10 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver
Preliminary steps
▶
"Removing backup and optical disk media" on page 74
.
▶
"Suspending BitLocker functionality" on page 71.
▶
"Shutting down the server" on page 45.
▶
"Disconnecting the power cord" on page 46.
▶
"Getting access to the component" on page 48.
Accessible drives
TX1320 M5 Upgrade and Maintenance Manual 261
