Fujitsu PRIMERGY TX1320 M5

Figure 164: Installing the RDX drive (B)
▶
Fasten the RDX drive to the drive cage with two screws.
Use the screw hole marked "1st".
Figure 165: Connecting cables to the RDX drive
Accessible drives
260 Upgrade and Maintenance Manual TX1320 M5
