Removing the Dual microSD 64GB Enterprise
Figure 224: Removing the Dual microSD 64GB Enterprise
▶
Disconnect the ROC cable from the connector "ROC" (1).
▶
Remove the Dual microSD 64GB Enterprise from the connector "USB 7" (2).
Concluding steps
▶
"Reassembling" on page
54.
▶
"Connecting the power cord" on page
57.
▶
"Switching on the server" on page 60.
17.7.4 Replacing the Dual microSD 64GB Enterprise
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: tool-less
System board and components
TX1320 M5 Upgrade and Maintenance Manual 333
