Fujitsu PRIMERGY TX1320 M5 User Manual

Installing the FBU tray
Figure 128: Installing the FBU tray
▶
Install the FBU tray into the bay and slide it into the bay as far as it will go.
Concluding steps
▶
"Connecting the front USB connector" on page
276
.
▶
"Reassembling" on page 54.
▶
"Connecting the power cord" on page 57.
▶
"Switching on the server" on page 60.
9.6.4 Replacing an FBU
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Tools: tool-less
Expansion cards and backup units
TX1320 M5 Upgrade and Maintenance Manual 219
