10.4 Removing memory modules
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: tool-less
Preliminary steps
▶
"Suspending BitLocker functionality" on page 71
.
▶
"Shutting down the server" on page 45.
▶
"Disconnecting the power cord" on page 46.
▶
"Getting access to the component" on page 48.
Removing a memory module
Figure 133: Removing memory modules (A)
▶
Eject the desired memory module by pressing out the securing clips at each
end of the memory slot.
Figure 134: Removing memory modules (B)
▶
Remove the ejected memory module.
Main memory
226 Upgrade and Maintenance Manual TX1320 M5
