â–¶
Connect the power cord to the PSU.
â–¶
Connect the mains connector to a grounded mains outlet in the in-house
power supply network.
â–¶
Ensure that the status indicator on the PSU is lit green, see "Indicator on
hot-plug PSU" on page 370.
You can secure the power cord with a cable clamp to ensure that the
power cord cannot be disconnected from the server by mistake. The
cable clamp is included in the accessories pack that is delivered
together with the server.
Figure 15: Locking the cable clamp of a PSU
â–¶
Pull the cable clamp up (1).
â–¶
Thread the power cord through the cable clamp (2).
â–¶
Press the cable clamp down until it engages to secure the cable (3).
It will take about 60 seconds until the server can be powered on.
Basic hardware procedures
TX1320 M5 Upgrade and Maintenance Manual 59
