Fujitsu PRIMERGY TX1320 M5

Figure 102: Inserting the SFP+ transceiver module
▶
Insert and slide the SFP+ transceiver module into the socket connector as
far as it will go.
Expansion cards and backup units
TX1320 M5 Upgrade and Maintenance Manual 189
