Tools: Phillips PH2 / (+) No. 2 screw driver
Preliminary steps
▶
"Locating the defective server" on page 43
.
▶
"Removing backup and optical disk media" on page 74.
▶
"Suspending BitLocker functionality" on page 71.
▶
"Shutting down the server" on page 45.
▶
"Disconnecting the power cord" on page 46.
▶
"Getting access to the component" on page 48.
Removing the defective RDX drive
▶
Remove the RDX drive, see "Removing the RDX drive" on page 261.
Installing the new RDX drive
▶
Install the RDX drive, see "Installing the RDX drive" on page 257.
Concluding steps
▶
"Reassembling" on page 54.
▶
"Connecting the power cord" on page 57.
▶
"Switching on the server" on page 60.
▶
"Resuming BitLocker functionality" on page 91.
Accessible drives
TX1320 M5 Upgrade and Maintenance Manual 265
