Fujitsu PRIMERGY TX1320 M5

Figure 174: Installing the front USB connector
▶
Run the front USB connector cable through the opening.
▶
Insert the FBU tray into the corresponding bay and slide it in as far as it will
go.
Front USB connector
TX1320 M5 Upgrade and Maintenance Manual 275
