Tools: Removing the system board:
– Phillips PH2 / (+) No. 2 screw driver
Removing the TPM:
–
Bit screw driver
– flat nose pliers
–
TPM bit insert
(*)
(*)
For Japan:
– TPM module fixing tool (S26361-F3552-L909)
CAUTION
▶
Advise your contact persons that they must provide you with all
recovery keys which belong to the system to restore them in the
TPM later.
Preliminary steps
Preliminary steps are not necessary, if a system board has to be
replaced and the TPM is used again.
▶
Before removing the TPM board, perform the following steps:
System board and components
TX1320 M5 Upgrade and Maintenance Manual 307
