Cable Notes and reference
Front panel cable
Power cable
Table 6: Minimum startup configuration - cables
▶
"Shutting down the server" on page 45.
▶
"Disconnecting the power cord" on page
46.
▶
Take the system down to its minimum startup configuration.
▶
"Connecting the power cord" on page 57.
▶
Connect a display to the server.
▶
"Switching on the server" on page 60.
CAUTION
▶
Since the fan module is not included in the minimum startup
configuration, the server must be shut down immediately after the
diagnostic process is complete (POST phase has been passed).
▶
The minimum startup configuration must be used exclusively for
diagnostic purposes by maintenance personnel, never in daily
operation!
Appendix A
374 Upgrade and Maintenance Manual TX1320 M5
