Breakout and recess in the HDD fan module
Figure 26: HDD fan module - breakout and recess
1 Breakout for the NVMe cables
If using a PCIe backplane:
â–¶
Break out the plastic flap of the HDD fan module by hand
(see oval) so that the NVMe cables can be run through the
breakout. This part can be disposed.
2 Recess for the power/OOB cable of SAS configuration
Basic hardware procedures
TX1320 M5 Upgrade and Maintenance Manual 69
