7.3 Handling HDDs or SSDs without installation frame 175
7.3.1 2.5-inch HDD/SSD and 2.5-inch installation frame 175
7.3.2 2.5-inch HDD/SSD and 3.5-inch installation frame 177
7.3.3 3.5-inch HDD and 3.5-inch installation frame 178
7.4 3.5-inch HDD configurations 181
7.4.1 Equipping the 3.5-inch HDD bays 181
7.4.2 Overview of configurations 181
7.4.2.1 Configuration with up to four HDD modules 181
7.4.2.2 Configuration with up to eight HDD modules 182
7.4.2.3 Configuration with up to 12 HDD modules 183
7.4.2.4 Configuration with additional PCIe SSD modules 184
7.4.3 Installing 3.5-inch HDD modules 185
7.4.4 Removing 3.5-inch HDD modules 188
7.4.5 Replacing a 3.5-inch HDD module 190
7.4.6 Replacing a 3.5-inch HDD backplane 192
7.4.7 Upgrading configuration from up to four to up to eight 3.5-inch
HDDs 203
7.5 2.5-inch HDD/SSD configurations 209
7.5.1 Overview of configurations 209
7.5.1.1 Configurations with up to eight HDD/SSD modules 209
7.5.1.2 Configurations with up to 16 HDD/SSD modules 210
7.5.1.3 Configurations with up to 24 HDD/SSD modules 211
7.5.1.4 Configurations with additional PCIe SSD modules 213
7.5.2 Installing 2.5-inch HDD/SSD modules 214
7.5.3 Removing 2.5-inch HDD/SSD modules 216
7.5.4 Replacing a 2.5-inch HDD/SSD module 219
7.5.5 Replacing a 2.5-inch HDD backplane 221
7.5.6 Upgrading configuration from eight to 16 2.5-inch HDDs/SSDs 236
7.6 HDD extension box 241
7.6.1 Installing the 8x 2.5-inch HDD/SSD extension box 241
7.6.2 Removing the 8x 2.5-inch HDD/SSD extension box 247
7.6.3 Replacing the HDD/SSD backplane or PCIe SSD on the 8x 2.5-
inch HDD/SSD extension box 250
7.6.4 Installing the 4x 3.5-inch HDD extension box 256
7.6.5 Removing the 4x 3.5-inch HDD extension box 260
Content
Upgrade and Maintenance Manual TX1330 M4
