Release all HDD/SSD modules and pull them out a few centimeters, see
"Removing 2.5-inch HDD/SSD modules" on page 216.
CAUTION
The HDD/SSD modules need not to be removed.
▶
If you want to remove them nevertheless, check if all HDD/SSD
modules are uniquely identified so that you can reinsert them
into their original bays.
▶
Release all dummy modules and pull them out a few centimeters, see
"Removing a 2.5-inch HDD/SSD dummy module" on page
215
.
▶
"Removing the defective system fan" on page 280.
▶
If applicable, "Removing the SAS expander board" on page 273.
▶
Disconnect all cables from the defective SAS backplane.
Removing the 2.5-inch HDD/SSD bay top cover
The 2.5-inch HDD/SSD front cover does not need to be removed in
order to replace a 2.5-inch HDD/SSD SAS backplane. In the figures, the
front cover has been removed for illustration purposes only.
Hard disk drive (HDD) / solid state disk (SSD)
222 Upgrade and Maintenance Manual TX1330 M4
