Preliminary steps
▶
"Suspending BitLocker functionality" on page 99
.
▶
"Shutting down the server" on page 47.
▶
"Disconnecting the power cord" on page 48.
▶
"Getting access to the component" on page 50.
▶
Remove the system fan module, see "Removing the system fan module" on
page 82.
▶
If applicable, remove the SAS expander board holder SAS expander board
holder without disconnecting cables, see "Removing the SAS expander
board holder" on page 273. Position the SAS expander board holder on the
HDD cages to get more space.
Removing the PCI slot cover
Figure 189: Removing the slot cover
▶
Fold up the locking handle on the slot cover clamp (1).
▶
Remove the slot cover clamp (2).
Expansion cards and backup units
300 Upgrade and Maintenance Manual TX1330 M4
