Remove the slot cover (3).
CAUTION
▶
Keep the slot cover for future use.
▶
If the expansion card is removed and not replaced with a new
one, the slot cover must be reinstalled due to cooling, to comply
with applicable EMC regulations and to protect against fire.
Installing the expansion card
If an optional FBU will be installed in the system, install a TFM on the
RAID controller, before proceeding.
▶
Remove the expansion card from its protective packaging.
For further instructions regarding controller settings, see the
accompanying documentation.
▶
If applicable, attach the required slot bracket to the expansion card, see
"Installing slot brackets" on page
289.
▶
If applicable, connect internal cables to the expansion card.
For the cable plan, see "Appendix B" on page 519
.
Expansion cards and backup units
TX1330 M4 Upgrade and Maintenance Manual 301
