Fujitsu PRIMERGY TX1330 M4

Figure 199: Removing the TFM
▶
Remove the two screws (1).
▶
Remove the TFM (2).
Note for replacing the TFM: The two spacer bolts can remain on the
RAID controller.
Installing the new TFM
Example RAID controller
Expansion cards and backup units
TX1330 M4 Upgrade and Maintenance Manual 315
