Add graduation marks to the syringe using a permanent marker to help
you apply the thermal paste.
Figure 226: Applying the thermal paste
▶
Apply a small point-shaped amount of thermal paste (1.0 gram, see
description above) to the center of the CPU surface as shown.
CAUTION
▶
Do not mix different types of thermal paste.
Processor (CPU)
TX1330 M4 Upgrade and Maintenance Manual 351
