Preliminary steps
▶
"Locating the defective server" on page 45
.
▶
"Shutting down the server" on page 47.
▶
"Disconnecting the power cord" on page 48.
▶
"Getting access to the component" on page 50.
▶
Remove the system fan module, see "Removing the system fan module" on
page 82.
Removing the defective heat sink
▶
Remove the heat sink, see "Removing the heat sink" on page 343.
▶
Remove the residual thermal paste from the CPU surface.
▶
Clean the CPU surface using a lint-free cloth.
Installing the new heat sink
▶
Remove the protective cover on the underside of the new heat sink.
CAUTION
▶
Do not touch the thermal paste on the underside of the heat sink.
▶
Install the heat sink, see "Installing the heat sink" on page
352
.
Concluding steps
▶
Install the system fan module, see "Installing the system fan module" on
page 85.
▶
"Reassembling" on page 66.
▶
"Connecting the power cord" on page 79.
▶
"Switching on the server" on page 81.
Processor (CPU)
354 Upgrade and Maintenance Manual TX1330 M4
