CAUTION
For that reason the front panel and system board must not be replaced
simultaneously! In this case, restoring the system configuration data on
the system board would fail.
When replacing the front panel, the system information like server name and
model, housing type, serial number and manufacturing data are not restored
automatically. So never forget to restore it manually by Chassis ID Prom Tool.
Preliminary steps
▶
"Locating the defective server" on page 45.
▶
"Suspending BitLocker functionality" on page 99.
▶
"Shutting down the server" on page 47.
▶
"Disconnecting the power cord" on page 48.
▶
"Getting access to the component" on page 50.
▶
Remove the system fan module, see "Removing the system fan module" on
page 82.
▶
If applicable, remove the SAS expander board holder without disconnecting
cables, see "Removing the SAS expander board holder" on page 273.
Position the SAS expander board holder on the HDD cages to get more
space.
Front panel
404 Upgrade and Maintenance Manual TX1330 M4
