Press the locking spring into direction of the arrow (1), so that the CMOS
battery jumps out of its socket.
▶
Remove the CMOS battery (2).
CAUTION
Sharp tools such as screw drivers might damage system board
components in case of slipping.
▶
If the CMOS battery cannot be ejected without the help of a tool,
it is recommended to use a tooth pick.
▶
Insert a new CMOS battery of the same type into the socket (3) and (4).
Concluding steps
▶
Dispose of the CMOS battery in accordance with local regulations
concerning special waste.
▶
If applicable, install the SAS expander board holder, see "Installing the SAS
expander board holder " on page
271.
▶
Install the system fan module, see "Installing the system fan module" on
page 85.
▶
"Reassembling" on page 66.
▶
"Connecting the power cord" on page 79.
▶
"Switching on the server" on page 81.
▶
BIOS settings are automatically reloaded. Time and date must be set
manually, see "Verifying the system time settings" on page 116.
You must manually change the BIOS settings according to the note
on your current BIOS settings, see "Note on BIOS settings recovery"
on page
415
.
System board and components
416 Upgrade and Maintenance Manual TX1330 M4
